224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯发电站用汽车发驱力汽油金钱性好: 比较好的的汽油操控模式，独具的STC、ESTC 分类操控模式，特有设定的火塞顶上一氧化碳汽缸，压力噴射汽油，能够有效做雾化，一氧化碳熔化能够有效。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯电站用起主观因素瞬态能出色: 好的起主观因素局部定制，听取康明斯独一无二的EFC程序，调节表面粗糙度提高，回复期限快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯带发电用汽车发驱力升最大功率高: 产品 制定密集.外观设计摆置恰当，作业平静。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷苹果机型 QSNT. QSK19. QSK38. QSK50实现中国现代非道路交通然后阶段中，及亚洲Tier2. Tier 3直接排放相关法律法规需要。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零备件管理应得性好， 发起机自动运行及维护与大保养大保养便利店加盟，直接费用低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

工作效率位置 Power Range   224-310KW结构 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外观寸尺 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净服务质量 Dry Weight   940kg

224-310KW康明斯发电厂用打着机的优势特点：比热容小， 减少比低， 格栅价格环境微波加热，便于开机启动，可移动车截电源线的常选。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

起因素规格	适用工率(kW)Prime Power	备用电源最大功率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
